NOF-156P02 Open Frame Panel PC
- Onboard Intel® Alder Lake-N Atom x7425E 1.5GHz, quad-core, 4 threads, (up to 3.4GHz)
- 15.6" Full HD 1920x1080, TFT-LCD
- Projected Capacitive Touch
- 2.5 GbE Ethernet ports x 2
- COM port x 2 (RS-232 x 1, RS-232/422/485 x 1)
- USB x 6 (3.2 Gen1 x 2, 3.2 Gen2 x 2, 2.0 x 2)
- DC 9~36V wide range power input
- Fan-less, modular detachable design
- Open Frame Rear mounting / VESA mounting
-
The Perfect Fit for Your Industrial Automation Needs!
Novakon's Open Frame Industrial Panel PC is engineered for seamless integration into automation, kiosks, and industrial applications. Powered by Intel® Alder Lake-N Atom x7425E, or 13th Gen Core™ i5-1335U 10-core processors, it features a durable, fanless design, high-performance computing, and a versatile open-frame structure, ensuring reliability in demanding environments. The NOF series is built for versatility across various industrial applications, from data acquisition and automation control to IIoT integration and advanced smart manufacturing. Designed for efficiency, the NOF delivers robust computing capabilities, making it the ideal solution for diverse industrial needs.
-
Specifications
Model NOF-156P02 Processor Onboard Intel® Alder Lake-N Atom x7425E 1.5GHz, quad-core, 4 threads, (up to 3.4GHz) Memory 1 x SO-DIMM, DDR5 4800MHz, up to 16GB Display Size 15.6" TFT-LCD Luminance (cd/m²) 350 (Typ.) Contrast 800:1 Max. Color 16.7M View Angle (H/V) 178 / 178 Backlight Lifetime (hrs) 50000 Touch Type Projected Capacitive Touch Touch Interface USB Light Transmission (%) Projected Capacitive Touch: over 84% USB 3.0 2 x USB 3.2 Gen 1, 2 x USB 3.2 Gen 2 USB 2.0 2 RS-232/422/485 Selectable under BIOS 1 RS-232 1 HDMI 2.0 1 Display Port 1 LAN 2 x 2.5GbE Audio 1 x Line Out Net Weight (kgs) 5 HDD 1 x M.2 key B (2280), SATA 6Gb/s/ PCIe x1 Power Input Range DC 9~36V Power Consumption 90W IP Rating Front Panel IP66 Mounting Rear mounting / VESA mounting 100x100mm / Panel mounting Operating Temperature 0~50° C (32~122° F) Storage Temperature -20~60° C (-4~140° F) Storage Humidity 10 to 90% (non-condensing) Certification CE / FCC CLASS A Software Option iFace-Designer® Runtime, Siemens Industrial Edge Runtime, Siemens Industrial Management Operating System Support Windows 10 IoT, Windows 11 IoT, Debian 11 Dimensions (mm) 418.4(W) x 268(H) x 68.1(D) -
Resources
Type Description File DRAWINGS NOF-156_2D Drawing NOF-156_2D Drawing
DATASHEETS NOF_Brochure NOF_Brochure
